Main Technical Features
- Nominal Capacity: 35,000 L (Elliptical tank body with anti-wave baffles)
- GVW: Up to 41,000 kg
- Tare Weight: 7,600–7,900 kg
- Axles: 3 × 9-ton axles (SAF / BPW / local options)
- Suspension: Air suspension + lift axle (mechanical optional)
- Brake System: WABCO / Knorr EBS, RSS, roll stability and emergency shut-off
- Material Options: ST52 carbon steel / AISI 304–316 stainless steel / aluminium on request
- Compartments: 3–5 segments (example: 15k + 10k + 10k)
- Manholes: 16" API approved manholes with vapour recovery
- Pumps: Gear, vane or turbine pumps depending on petroleum product type
- Discharge System: Gravity / Pumped / Bottom-loading API system
- Compliance: ADR + EC Type Approval (export-ready)
- Painting: 2-component epoxy primer + polyurethane topcoat
Why Choose Alura Trailer?
- ✔ Internal baffle system ensures stability and eliminates wave movement during braking.
- ✔ ADR-certified components (valves, hoses, breathing system, emergency shut-off).
- ✔ API-approved top & bottom loading system for fast depot operations.
- ✔ Customizable tank material: carbon steel, stainless, or aluminium.
- ✔ Delivered to 30+ countries with full export documentation.
Technical Drawing
Below is the exact engineering layout including tank geometry, frame structure and component positioning.
Global Delivery
All tanker semi-trailers are manufactured in Türkiye with EC Type Approval and ADR certification. Alura Trailer provides global shipment support including Ro-Ro, flat rack, containerization, and land transport.
