Capacity & Payload
- Axles Load: 36 Tons (12 x 3)
- King-Pin Load: 16 Tons
- Tare Weight: 10 Tons (±2%)
- Payload Capacity: 32 Tons (±2%)
General Technical Specifications
- Main Chassis: Reinforced “I” section undercarriage made of ST52 steel
- Structure: Combination of lower & upper sheet bars with central hub steel sheet
- Welding Technology: Shielded metal arc electrode welding
- Floor: Wood-covered platform with patterned steel sheet on lower and side sections
- Suspension Beam: Fixed suspension beam with aluminum-covered side sections
- King Pin: Demountable DIN standard, 2” or 3.5” double king pin
- Tow Truck Compatibility: Suitable for 4x2, 6x2 or 6x4 tractor units
Axles, Suspension & Tyres
- Axles: 3 × 12 Ton drum brake axles
- Suspension: Air suspension on all 3 axles
- Lifting System: Front axle lifting system
- Tyres: 245/70 R17.5 – 12 + 1 spare
Hydraulic Rear Ramps
The trailer is equipped with heavy-duty hydraulic rear ramps designed for loading and unloading construction machinery and wheeled equipment safely and efficiently.
- ✔ Hydraulic operation with remote control
- ✔ Adjustable up/down movement
- ✔ Adjustable side positioning
- ✔ High load-bearing ramp structure
Brake & Electrical System
- Brake System: 2s/2m – 4s/2m EBS braking system (WABCO)
- Electrical System: 2x7 pinned SAE standard complete lighting system
- Rear Stop Lamps: 7-function rear stop lamps
- Front Lamps: 2 white LED illuminated lamps
- Side Lamps: 4 × 2 yellow LED side lamps
- Plate Lamps: 2 traffic license plate lamps
- Additional: Rear rotating warning lamp
Applications
- ✔ Construction machinery
- ✔ Excavators & loaders
- ✔ Industrial equipment
- ✔ Heavy and oversized cargo
Durability & Engineering Quality
- ✔ High-strength ST52 steel chassis
- ✔ Fatigue-tested welded joints
- ✔ Reinforced king pin & suspension zones
- ✔ Designed for long-term heavy-duty operation
Global Delivery & Certification
All Alura lowbed semi trailers are manufactured in compliance with international transport regulations and delivered with full export documentation. EBS conformity and global shipping support are provided.
Download PDF or Request a Quote
Payload Feasibility Calculator
Use this calculator to check whether your cargo weight is suitable for the 3 Axles Lowbed Semi Trailer (32 ton payload capacity).
* This calculator provides an estimated feasibility check. Final payload approval depends on axle load distribution and load positioning.
